Behavioral neuroscience discoveries have proceeded at a rapid pace. This series highlights cutting-edge findings and explains their importance for neurofeedback providers and their clients. This initial installment focuses on sleep.
Click on our narrator icon to listen to this post.
Sleep Architecture Overview
We can divide sleep into non-REM (NREM) sleep which contains three stages, and rapid eye movement (REM) sleep. Stage 3 sleep (NREM3), termed slow-wave sleep and REM sleep, are arguably the most crucial stages. Following total sleep deprivation, we spend more time in Stage 3 on night one and in REM on night two (Breedlove & Watson, 2023). Graphic retrieved from Healing Touch Diagnostics.
An average night’s sleep contains 4-5 cycles, 90-110 minutes each. Adults spend about 20% of total sleep in REM. Early cycles contain more stage 3 slow wave sleep (SWS), while later cycles contain increasing amounts of REM sleep (Breedlove & Watson, 2023). The hormone hypocretin regulates the order of our sleep stages. Excessive hypocretin is associated with insomnia, whereas deficient hypocretin is observed in narcolepsy (Holm et al., 2022).
Why Is SWS Important?
SWS performs four functions vital to brain health and performance: growth hormone release, glymphatic system waste removal, replenishing astrocyte glycogen stores, and consolidating memory.
Growth Hormone Release
The body releases most growth hormone (GH; somatotropin) during SWS in the first half of the night. GH promotes bodywide tissue growth and repair by influencing protein metabolism (Breedlove & Watson, 2023).
At age 60, we spend half the time in stage 3 compared with age 20. Stage 3 sleep disappears by age 90, and its loss may be associated with cognitive impairment. Patients diagnosed with senile dementia spend significantly less time in Stage 3 (Kondratova & Kondratova, 2012). Growth hormone loss due to sleep disruption and the progressive reduction in Stage 3 sleep may cause cognitive deficits.
Glymphatic System Waste Removal
The human brain contains a recently-discovered glymphatic system. This astrocyte-controlled lymphatic system removes cellular debris, proteins, and wastes (Xie et al., 2013). The flushing of toxic substances may protect us from neurological disorders like Alzheimer’s (Breedlove & Watson, 2023).
Jeff Illiff showed waste removal in mice brains during sleep in his excellent 2014 TED MED Talk, One More Reason to Get a Good Night's Sleep. However, the discovery of the glymphatic system contradicted his view that there are no lymphatic vessels in the brain.
Cerebrospinal fluid (CSF) flows from the subarachnoid space to travel outside pulsing arteries. CSF enters the brain via aquaporins and collects waste. Finally, CSF enters the perivascular space surrounding capillaries and is removed by venous circulation.
Stage 3 sleep accelerates the glymphatic system’s clearance of β-amyloid (Holth et al., 2019). Immune cells in the brain play key role in relationship between gut microbes and beta-amyloid. Graphic © Juan Gaertner/shutterstock.com.
β-amyloid may initiate a cascade that transforms tau protein into a highly toxic molecule (Zhang et al., 2020).
Replenishing Astrocyte Glycogen Stores
Astrocytes are star-shaped glial cells that comprise part of the protective blood-brain barrier (BBB). The human brain primarily stores the energy source glycogen in astrocytes (Öz et al., 2007). Astrocyte graphic © Kateryna Kon/Shutterstock.com.
Due to generally reduced metabolic demand compared with waking, stage 3 sleep allows astrocytes to rebuild their energy reserves when demand from neurons is the lowest. Astrocytes release glycogen to neurons during peak activity when we are awake (Bellesi et al., 2018; Schummers et al., 2008).
Neurons convert glycogen to glucose. Glycolysis and oxidative phosphorylation transform glucose into ATP (Ashrafi & Ryan, 2017). ATP powers vital neuronal functions like the sodium-potassium pumps, which restore a neuron's membrane potential. Graphic © Designua/ Shutterstock.com.
Consolidating Memory
NREM sleep helps to consolidate declarative memories, which are memories we can describe (Nishida & Walker, 2007). In contrast, sleep deprivation helps to create false memories (Marshall et al., 2006). Norepinephrine (NE) levels rise and fall every 30 seconds in the sleeping mouse brain. The peaks (high NE levels) are associated with more than 100 brief awakenings that may aid memory consolidation. The valleys (low NE levels) occur when they are asleep (Kjaerby et al., 2022). Memory consolidation during NREM sleep appears to involve replaying the pattern of
neuronal firing observed when learning a task (Euston et al., 2007).
Each NREM slow wave is a “courier” that moves “packets of information” between anatomical regions (Walker, 2018).
NREM slow waves transfer fragile short-term memories from temporary (hippocampal) to long-term (cortical) storage.
Ripples Contribute to Human Memory Consolidation
We store a memory's sensory elements in specialized areas (e.g., auditory and visual) distributed across the cortex. The brain may coordinate these widespread networks during sleep and waking through synchronized 90-Hz oscillations called ripples.
During waking, cortical ripples occur on local high-frequency activity peaks. During sleep, cortical ripples typically occur on the cortical down-to-upstate transition, often with 10- to 16-Hz cortical sleep spindles, and local unit firing patterns consistent with generation by pyramidal-interneuron feedback. We found that cortical ripples group cofiring within the window of spike-timing-dependent plasticity. These findings are consistent with cortical ripples contributing to memory consolidation during NREM in humans (Dickey et al., 2022)
NREM-REM Partnership
The consolidation process may also determine which synapses survive and which are pruned away. NREM sleep consolidates new information, and REM sleep integrates it with our experience. NREM sleep removes outdated synapses, while REM sleep strengthens necessary connections. Graphic © Christoph Burgstedt/Shutterstock.com.
Why Is REM Sleep Important?
Rapid eye movements during REM sleep track the dream imagery created by mouse brains (Senzai & Scanziani, 2022).
Jagged sawtooth waves (STWs) during REM sleep may synchronize the replay of memories to consolidate them (Frauscher et al., 2020). Graphic © The Atlas of Adult Electroencephalography.
REM sleep revises autobiographical memories to reflect the previous day’s events (Walker, 2018). Below, oligodendrocytes mediate memory formation in the central nervous system (Fields, 2019).
Graphic © Juan Gaertner/Shutterstock.com.
The interaction between NREM and REM sleep remodels neural circuitry based on current priorities to efficiently manage our brain’s limited storage capacity (Walker, 2018).
From Hutchinson and Rathore's (2015) perspective, REM sleep may strengthen and modify emotional memories.
. . . REM sleep represents a unique brain state that allows the emotionally modulated integration and recombination of neocortical memory traces previously consolidated during NREM sleep. In addition, we suggest that REM sleep is involved in the gradual disengagement of successfully consolidated memory traces from the hippocampus—thus mediating the decontextualization of novel memories, allowing generalization, abstraction, etc.
Why Does Sleep Matter?
1. Sleeping less than 6 hours a night is associated with adverse health outcomes and increased mortality (Cappuccio et al., 2010)
2. Insomnia is linked to an increased risk of Alzheimer’s and other neurodegenerative diseases (Sadeghmousavi et al., 2020).
3. Sleep disorders can trigger episodes of disorders like depression and schizophrenia (Khurshid, 2018).
4. Insomnia impairs executive functions like continuous attention and problem-solving, impairing performance (Ballesio et al., 2019). Graphic © TheVisualsYouNeed/Shutterstock.com.
Insufficient sleep is associated with diverse health and performance problems.
How Has the COVID-19 Pandemic Impacted Sleep?
The pandemic has worsened insomnia due to:
1. the disruption of routines, including exercise
2. loss of time anchors (e.g., commuting to work) 3. reduced daylight exposure; increased screen time
4. excessive napping and oversleeping
5. worry and anxiety due to financial and health uncertainty, amplified by COVID fatigue, loss of privacy, and social media
6. social isolation, grief, and depression
7. family/work stress due when entire families shelter in place
8. major increase in screen time, resulting in reduced melatonin release and less sleep pressure
9. stress-related fatigue that robs you of energy and motivation when you wake up
10. increased substance misuse and relapse of substance use disorders
11. relapsing or worsening health problems (SleepFoundation.org, 2020)
Evidence-Based Interventions
Good sleep hygiene is critical for health and successful biofeedback and neurofeedback training. For example, ambient bedroom light can disrupt sleep, lower heart rate variability, and increase insulin resistance.
Sharon Begley and Inna Khazan separately contributed several evidence-based strategies.
1. Sleep in a darkened room.
Why? One night's exposure to bedroom illumination of ~100 lux increased heart rate, decreased heart rate variability, and increased next-morning insulin resistance compared to < 3 lux (Mason et al., 2022). In addition, sleeping with ambient light increases alertness, delays sleep onset, and suppresses melatonin secretion, dysregulating circadian rhythms (Cho et al., 2015). Graphic © Ground Picture/Shutterstock.com.
2. Avoid blue light before bed.
Why? Blue light from an iPad after 9 pm can delay your circadian rhythm by an hour and reduce the restfulness of even 8 hours of sleep (Chang et al., 2015).
In addition, exposure to bright screens 2 hours before bedtime can delay sleep onset. Graphic © Subbotina Anna/Shutterstock.com.
Instead? Swap a paperback for an iPad. (Undergrads might have to Google paperback.) Apple’s Night Shift mode still significantly suppresses melatonin which regulates your circadian rhythm (Nagare et al., 2018).
3. Stop hitting the snooze button.
Why? When you return to sleep and awaken minutes later, you may experience the grogginess of sleep inertia. This can interfere with attention and memory.
Instead? Make your sleep schedule more consistent, allow morning light to awaken you, and adjust your circadian rhythm.
4. Experience daylight.
Why? Daylight is one of the most effective circadian cues. In one small study (Boubekri et al., 2014), workers with windows reported better global sleep quality and fewer disturbances than those without.
How? When your office desk doesn’t provide sunlight, you can walk during your lunch hour to reconnect with this circadian cue. Alternatively, use a full-spectrum lamp.
5. Skip alcohol before bed.
Why? While alcohol may help you get to sleep more quickly, it reduces REM sleep (Ebrahim et al., 2013) and increases nighttime urination. This can cause drowsiness, impaired concentration, and failure to integrate new information. Graphic © Lysenko Andrii/Shutterstock.com.
6. Exercise to lengthen sleep time.
Why? Thirty minutes of afternoon exercise at least three times a week increased elderly participants’ sleep duration by 45-60 minutes after 4 months (Baron et al., 2013). Graphic © Lordn/Shutterstock.com.
Cautions? Don’t exercise 4 hours before bedtime because exercise activates your nervous system and raises core body temperature. Passive stretching and yoga are fine (Khazan, 2019).
7. Put away the clock once in bed.
Why? Looking at the clock while in bed can increase activation and anxiety, disrupting sleep.
Instead? Cover or remove clocks and hide your cell phone.
8. Watch eating and drinking before bed.
Why? Since digestion slows when you sleep, heavy meals 4 hours before bedtime can awaken you. This is critical if you experience heartburn. Drinking fluids before bedtime can increase the frequency of nighttime urination, fragmenting sleep. Instead? Limit food intake to light snacks and stop liquids for 2 hours (alcohol at least 3 hours) before bedtime.
9. Don’t nap.
Why? Stanford sleep researcher Donn Posner compares napping to eating snacks before dinner. Naps make us less drowsy since they decrease sleep pressure. However, naps are less disruptive for habitual nappers (Hirschlag, 2020).
Summary
Sleep is critical for health and optimal performance. Clients whose sleep architecture and duration satisfy their individual needs often achieve better executive functioning and self-regulation.
The discovery of the glymphatic system and its role in waste clearance during SWS was one of the most important discoveries in the neuroscience of sleep. This breakthrough revealed that the lymphatic system encompasses the brain and clears most wastes during SWS. Sleep disorders that reduce SWS risk the buildup of proteins that may promote neurodegenerative diseases like Alzheimer's. The finding that growth hormone is released during SWS, which steadily declines with aging until it disappears by age 90, provides another explanation for reduced brain repair and neurodegeneration.
The eight evidence-based recommendations provide a foundation for good sleep hygiene. Suppose clients continue to experience insomnia after implementing these suggestions. In that case, they might consult their physician for a home sleep study that could justify an in-clinic study at an accredited sleep laboratory.
Glossary
astrocytes: star-shaped glial cells that communicate with and support neurons and help determine whether synapses will form.
β-amyloid: the main constituent of amyloid plaques found in Alzheimer's patients.
glucose: a simple sugar that is the body's main energy source.
glycogen: the stored form of glucose comprised of many connected glucose molecules.
glymphatic system: an astrocyte-controlled lymphatic system that removes cellular debris, proteins, and wastes from the brain.
growth hormone (GH, somatotropin): an anterior pituitary tropic hormone released during SWS that regulates cell and tissue growth.
hypnogram: a diagram that summarizes the stages of sleep recorded in the sleep laboratory.
hypocretin (orexin): a peptide hormone that regulates the transition between sleep stages.
insomnia: a condition marked by trouble falling asleep or staying asleep.
insulin resistance: impaired insulin utilization resulting in elevated blood glucose.
melatonin: a hormone that helps regulate circadian rhythms, produced in a predictable
daily rhythm by the pineal gland.
non-REM (NREM) sleep: sleep stages without rapid eye movements, divided into stages 1, 2, and 3 sleep.
oligodendrocytes: glial cells that insulate adjacent axons within the brain and spinal cord of the central nervous system.
rapid eye movement (REM) sleep: also called paradoxical sleep. A sleep stage characterized by small-amplitude, fast EEG waves, no postural tension, and rapid eye movements.
ripples: synchronized high-frequency (90-Hz) cortical oscillations that coordinate widespread cortical networks during sleep and waking to bind sensory elements and consolidate memory.
sawtooth waves (STW): bursts of slow oscillations in the scalp EEG.
sleep architecture: the pattern made when sleep stages are charted on a hypnogram.
sleep cycle: a period of slow-wave sleep followed by a period of REM sleep that typically lasts 90-110 minutes.
sleep deprivation: the partial or total prevention of sleep.
sleep hygiene: habits, like stopping caffeine in the afternoon, that promote healthy sleep.
sleep recovery: the process of sleeping more than is normal after a period of sleep deprivation as though in compensation.
stage 1 sleep: also called NREM1. The initial stage of NREM sleep, which is characterized by small-amplitude EEG waves of irregular frequency, slow heart rate, and reduced muscle tension.
stage 2 sleep: also called NREM2. A stage of NREM sleep that is defined by bursts of EEG waves called sleep spindles.
stage 3 sleep: also called NREM3. A stage of NREM sleep that is defined by the presence of large-amplitude, very slow waves (delta waves).
tau protein: a protein that helps stabilize axon microtubules but can produce toxic neurofibrillary tangles when modified.
theta rhythm: 4-8-Hz rhythms generated a cholinergic septohippocampal system that receives input from the ascending reticular formation and a noncholinergic system that originates in the entorhinal cortex, which corresponds to Brodmann areas 28 and 34 at the caudal region of the temporal lobe.
References
Ashrafi, G., & Ryan, T. A. (2017). Glucose metabolism in nerve terminals. Current opinion in neurobiology, 45, 156–161. https://doi.org/10.1016/j.conb.2017.03.007
Ballesio, A., Aquino, M. R. J. V., Kyle, S. D., Ferlazzo, F., & Lombardo, C. (2019). Executive functions in Insomnia Disorder: A systematic review and exploratory meta-analysis. Frontiers in psychology, 10, 101. https://doi.org/10.3389/fpsyg.2019.00101
Baron, K. G., Reid, K. J., & Zee, P. C. (2013). Exercise to improve sleep in insomnia: Exploration of the bidirectional effects. Journal of clinical sleep medicine: JCSM: official publication of the American Academy of Sleep Medicine, 9(8), 819–824. https://doi.org/10.5664/jcsm.2930
Begley, S. (2018). The 9 new sleep rules. The science of sleep. Time.
Bellesi, M., de Vivo, L., Koebe, S., Tononi, G., & Cirelli, C. (2018). Sleep and wake affect glycogen content and turnover at perisynaptic astrocytic processes. Frontiers in cellular neuroscience, 12, 308. https://doi.org/10.3389/fncel.2018.00308
Boubekri, M., Cheung, I. N., Reid, K. J., Wang, C. H., & Zee, P. C. (2014). Impact of windows and daylight exposure on overall health and sleep quality of office workers: A case-control pilot study. Journal of clinical sleep medicine: JCSM: official publication of the American Academy of Sleep Medicine, 10(6), 603–611. https://doi.org/10.5664/jcsm.3780
Breedlove, S. M., & Watson, N. V. (2023). Behavioral neuroscience (10th ed.). Sinauer Associates.
Cappuccio, F. P., D'Elia, L., Strazzullo, P., & Miller, M. A. (2010). Sleep duration and all-cause mortality: a systematic review and meta-analysis of prospective studies. Sleep, 33(5), 585–592. https://doi.org/10.1093/sleep/33.5.585
Cho, Y., Ryu, S. H., Lee, B. R., Kim, K. H., Lee, E., & Choi, J. (2015). Effects of artificial light at night on human health: A literature review of observational and experimental studies applied to exposure assessment. Chronobiology international, 32(9), 1294–1310. https://doi.org/10.3109/07420528.2015.1073158
Dickey, C. W., Verzhbinsky, I. A., Jiang, X., Rosen, B. Q., Kajfez, S., Stedelin, B., Shih, J. J., Ben-Haim, S., Raslan, A. M., Eskandar, E. N., Gonzalez-Martinez, J., Cash, S. S., & Halgren, E. (2022). Widespread ripples synchronize human cortical activity during sleep, waking, and memory recall. Proceedings of the National Academy of Sciences of the United States of America, 119(28), e2107797119. https://doi.org/10.1073/pnas.2107797119
Ebrahim, I. O., Shapiro, C. M., Williams, A. J., & Fenwick, P. B. (2013). Alcohol and sleep I: Effects on normal sleep. Alcoholism, clinical and experimental research, 37(4), 539–549. https://doi.org/10.1111/acer.12006
Euston, D. R., Tatsuno, M., & McNaughton, B. L. (2007). Fast-forward playback of recent memory sequences in prefrontal cortex during sleep. Science, 318(5853), 1147–1150. https://doi.org/10.1126/science.1148979
Fields, R. D. (2018). Deeper insights emerge into how memories form. Scientific American.
Frauscher, B., von Ellenrieder, N., Dolezalova, I., Bouhadoun, S., Gotman, J., & Peter-Derex, L. (2020). Rapid eye movement sleep sawtooth waves are associated with widespread cortical activations. The Journal of Neuroscience, 40(46) 8900-8912. https://doi.org/10.1523/JNEUROSCI.1586-20.2020
Hablitz, L. M., Vinitsky, H. S., Sun, Q., Stæger, F. F., Sigurdsson, B., Mortensen, K. N., Lilius, T. O., & Nedergaard, M. (2019). Increased glymphatic influx is correlated with high EEG delta power and low heart rate in mice under anesthesia. Science advances, 5(2), eaav5447. https://doi.org/10.1126/sciadv.aav5447
Holth, J. K., Fritschi, S. K., Wang, C., Pedersen, N. P., Cirrito, J. R., Mahan, T. E., Finn, M. N., Manis, M., Geerling, J. C., Fuller, P. M., Lucey, B. P., & Holtzman, D. M. (2019). The sleep-wake cycle regulates brain interstitial fluid in mice and CSF tau in humans. Science, 363(6429), 880-884.
Holm, A., Possovre, M. L., Bandarabadi, M., Moseholm, K. F., Justinussen, J. L., Bozic, I., Lemcke, R., Arribat, Y., Amati, F., Silahtaroglu, A., Juventin, M., Adamantidis, A., Tafti, M., & Kornum, B. R. (2022). The evolutionarily conserved miRNA-137 targets the neuropeptide hypocretin/orexin and modulates the wake to sleep ratio. Proceedings of the National Academy of Sciences of the United States of America, 119(17), e2112225119. https://doi.org/10.1073/pnas.2112225119
Hutchison, I. C., & Rathore, S. (2015). The role of REM sleep theta activity in emotional memory. Frontiers in psychology, 6, 1439. https://doi.org/10.3389/fpsyg.2015.01439
Khazan, I. (2019). Biofeedback and mindfulness in everyday life. W. W. Norton & Company.
Khurshid K. A. (2018). Comorbid insomnia and psychiatric disorders: An update. Innovations in clinical neuroscience, 15(3-4), 28–32. PMID: 29707424
Kjaerby, C., Andersen, M., Hauglund, N., Untiet, V., Dall, C., Sigurdsson, B., Ding, F., Feng, J., Li, Y., Weikop, P., Hirase, H., & Nedergaard, M. (2022). Memory-enhancing properties of sleep depend on the oscillatory amplitude of norepinephrine. Nature neuroscience, 25(8), 1059–1070. https://doi.org/10.1038/s41593-022-01102-9
Kondratova, A. A., & Kondratov, R. V. (2012). The circadian clock and pathology of the ageing brain. Nature reviews. Neuroscience, 13(5), 325–335. https://doi.org/10.1038/nrn3208
Marshall, L., Helgadóttir, H., Mölle, M., & Born, J. (2006). Boosting slow oscillations during sleep potentiates memory. Nature, 444, 610-613. https://doi.org/10.1038/nature05278
Mason, I. C., Grimaldi, D., Reid, K. J., Warlick, C. D., Malkani, R. G., Abbott, S. M., & Zee, P. C. (2022). Light exposure during sleep impairs cardiometabolic function. Proceedings of the National Academy of Sciences of the United States of America, 119(12), e2113290119. https://doi.org/10.1073/pnas.2113290119
Nagare, R., Plitnick, B., & Figueiro, M. G. (2019). Does the iPad Night Shift mode reduce melatonin suppression? Lighting research & technology, 51(3), 373–383. https://doi.org/10.1177/1477153517748189
Nishida, M., & Walker, M. P. (2007). Daytime naps, motor memory consolidation and regionally specific sleep spindles. PloS one, 2(4), e341. https://doi.org/10.1371/journal.pone.0000341
Öz, G., Seaquist, E. R., Kumar, A., Criego, A. B., Benedict, L. E., Rao, J. P., Henry, P. G., Van De Moortele, P. F., & Gruetter, R. (2007). Human brain glycogen content and metabolism: implications on its role in brain energy metabolism. American journal of physiology. Endocrinology and metabolism, 292(3), E946–E951. https://doi.org/10.1152/ajpendo.00424.2006
Sadeghmousavi, S., Eskian, M., Rahmani, F., & Rezaei, N. (2020). The effect of insomnia on development of Alzheimer's disease. Journal of neuroinflammation, 17(1), 289. https://doi.org/10.1186/s12974-020-01960-9
Schummers, J., Yu, H., & Sur, M. (2008). Tuned responses of astrocytes and their influence on hemodynamic signals in the visual cortex. Science, 320(5883), 1638–1643. https://doi.org/10.1126/science.1156120
Senzai, Y., & Scanziani, M. (2022). A cognitive process occurring during sleep is revealed by rapid eye movements. Science, 377(6609), 999–1004. https://doi.org/10.1126/science.abp8852 Smiley, A., Wolter, S., & Nissan, D. (2019). Mechanisms of association of sleep and Metabolic Syndrome. Journal of Medical - Clinical Research & Reviews, 3(3). http://dx.doi.org/10.33425/2639-944X.1089
Walker, M. (2018). Why we sleep: Unlocking the power of sleep and dreams. Scribner.
Wostyn, P., & Goddaer, P. (2022). Can meditation-based approaches improve the cleansing power of the glymphatic system? Explor Neuroprot Ther, 2,110–117. https://doi.org/10.37349/ent.2022.00022
Xie, L., Kang, H., Xu, Q., Chen, M. J., Liao, Y., Thiyagarajan, M., O'Donnell, J., Christensen, D. J., Nicholson, C., Iliff, J. J., Takano, T., Deane, R., & Nedergaard, M. (2013). Sleep drives metabolite clearance from the adult brain. Science, 342(6156), 373–377. https://doi.org/10.1126/science.1241224
Zhang, F., Gannon, M., Chen, Y., Yan, S., Zhang, S., Feng, W., Tao, J., Sha, B., Liu, Z., Saito, T., Saido, T., Keene, C. D., Jiao, K., Roberson, E. D., Xu, H., & Wang, Q. (2020). β-amyloid redirects norepinephrine signaling to activate the pathogenic GSK3β/tau cascade. Science translational medicine, 12(526), eaay6931. https://doi.org/10.1126/scitranslmed.aay6931
